DiskStation® DS723+
Compact and capable storage for home and small business
Take your data management to the next level
Versatile smart storage that helps you consolidate and store your growing digital data.
Click to Download Datasheet
- Stunningly compact : Powerful functionality in a tiny package, with room for 10GbE and dual NVMe drives.
- Consolidate and share : Flexibly store and organize 50 TB of data, then share with anyone.
- Keep your data safe : Hardware and software engineered to protect your data — trusted by millions.
Simply faster
The DS723+ can handle demanding application workloads and a greater number of concurrent users. Experience faster file indexing in Synology Drive, photo organization in Photos, and concurrent file transfers.
- Synology Drive : 24% faster file indexing
- Synology Photos : 25% faster photo indexing
-
Multiple file transfers : 32% faster random write
The performance you need
Reduce transfer times with the DS723+, designed to accelerate your workloads. Easily add faster networking and NVMe drives to further boost performance.
- Up to471/225 MB/sread/write1
- Up to10GbEnetworking2
- 2 x M.2NVMecache & storage pool3
Versatile and flexible storage
Make the most of high-performance networking and file access without taking up unnecessary space. DS723+ comes equipped with 2 bays and can scale up to 7 bays with the DX517 expansion unit as your data needs grow.
2 bays18 TB >> 7 bays90 TB
Store, share, and protect
Manage all your documents, photos, and other files, back up applications and devices, and protect your assets with professional video surveillance.
Private cloud storage
Access files from all your devices and protect them with smart versioning. Manage, share, and sync your data across locations.
Consolidate Data Magement
A private cloud for all your devices
Effortlessly deploy your own personal cloud with Synology’s private cloud solution. Simplify file access and consolidate your data management to benefit from easier file sharing and collaboration.
Professional photo management
Efficiently back up and organize photos and videos with management tools for novice and professional users alike. Automatically organize your content into albums and create secure share links to share files with family, friends, or clients.
Collaborate across Sites
Sync files and folders between sites
Site-to-site file syncing allows collaborators to sync individual files or folders between Synology devices, whether at home, another office, or across the world. Combine convenient access with 100% data ownership.
Share data with the power of the cloud
Reduce your on-site storage footprint and benefit from data center network speeds with hybrid cloud technology. Set up Hybrid Share Folders4 to efficiently store cold data in the cloud, while keeping frequently accessed files cached locally on your DS723+ and accessible at LAN speeds. Learn more
Multi-layered backup
Back up files, folders, physical devices, VMs, and SaaS applications with free solutions, and protect your NAS with built-in technologies.
Smart surveillance
Transform your Synology device into a full-featured video management system for a wide range of compatible IP cameras.
Performance backed by Synology drives
Leverage high sustained performance and reliability with enterprise-grade drives with built-in data protection designed for Synology systems.2
3.5” HDD HAT5300 Series2.5” SSD SAT5200 Series
Get more with DiskStation Manager
Take advantage of a host of native productivity, management, and security solutions available in the web-based Synology DSM operating system.
Central Management System :
Conveniently manage your fleet of Synology NAS from a centralized console.
Security:
Shield your Synology NAS from the most sophisticated threats with industry-leading security solutions.
Synology High Availability:
Seamless transition between clustered servers in the event of a server failure to minimize the impact on applications.
Synology has you covered
The DS723+ is backed by Synology’s 3-year hardware warranty.6 An optional 2-year extended warranty is available in select regions to extend coverage to 5 years. Learn more
Specifications
HARDWARE SPECS
|
CPU |
CPU Model | AMD Ryzen R1600 |
|---|---|---|
| CPU Quantity | 1 | |
| CPU Architecture | 64-bit | |
| CPU Frequency | 2-core 2.6 (base) / 3.1 (turbo) GHz | |
| Hardware Encryption Engine (AES-NI) | ||
|
Memory |
System Memory | 2 GB DDR4 ECC |
| Memory Module Pre-installed | 2 GB (2 GB x 1) | |
| Total Memory Slots | 2 | |
| Maximum Memory Capacity | 32 GB (16 GB x 2) | |
| Notes |
|
|
|
Storage |
Drive Bays | 2 |
| Maximum Drive Bays with Expansion Unit | 7 (DX517 x 1) | |
| M.2 Drive Slots | 2 (NVMe) | |
| Compatible Drive Type* (See all supported drives) |
|
|
| Hot Swappable Drive* | ||
| Notes |
|
|
|
External Ports |
RJ-45 1GbE LAN Port* | 2 (with Link Aggregation / Failover support) |
| USB 3.2 Gen 1 Port* | 1 | |
| eSATA Port | 1 | |
| Notes |
|
|
|
PCIe |
PCIe Expansion | 1 x Gen3 x2 network upgrade slot |
|
File System |
Internal Drives |
|
| External Drives |
|
|
|
Appearance |
Size (Height x Width x Depth) | 166 mm x 106 mm x 223 mm |
| Weight | 1.51 kg | |
|
Others |
System Fan | 92 mm x 92 mm x 1 pcs |
| Fan Speed Mode |
|
|
| Brightness Adjustable Front LED Indicators | ||
| Power Recovery | ||
| Noise Level* | 20.7 dB(A) | |
| Scheduled Power On / Off | ||
| Wake on LAN / WAN | ||
| Power Supply Unit / Adapter | 65 W | |
| AC Input Power Voltage | 100V to 240V AC | |
| Power Frequency | 50/60 Hz, Single Phase | |
| Power Consumption |
21.07 W (Access) 8.62 W (HDD Hibernation) |
|
| British Thermal Unit |
71.85 BTU/hr (Access) 29.39 BTU/hr (HDD Hibernation) |
|
| Notes |
|
|
|
Temperature |
Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Storage Temperature | -20°C to 60°C (-5°F to 140°F) | |
| Relative Humidity | 5% to 95% RH | |
|
Certification |
|
|
|
Warranty |
3-year hardware warranty, extendable to 5 years with EW201 | |
| Notes |
|
|
|
Environment |
RoHS Compliant | |
|
Packaging Content |
|
|
|
Optional Accessories |
|
|
SOFTWARE SPECS
|
DSM Specifications |
||
|---|---|---|
| Maximum Single Volume Size* | 108 TB | |
| Maximum Internal Volume Number | 64 | |
| M.2 SSD Storage Pool Support* | ||
| SSD Read / Write Cache (White Paper) | ||
| SSD TRIM | ||
| Supported RAID Type |
|
|
| RAID Migration |
|
|
| Volume Expansion with Larger HDDs |
|
|
| Volume Expansion by Adding a HDD |
|
|
| Global Hot Spare Supported RAID Type |
|
|
| Notes |
|
|
| File Protocol | SMB/AFP/NFS/FTP/WebDAV | |
| Maximum Concurrent SMB/AFP/FTP Connections | 500 | |
| Maximum Concurrent SMB/AFP/FTP Connections (with RAM expansion) | 2,000 | |
| Windows Access Control List (ACL) Integration | ||
| NFS Kerberos Authentication | ||
| Notes |
|
|
| Maximum Local User Accounts | 2,048 | |
| Maximum Local Groups | 256 | |
| Maximum Shared Folder | 512 | |
| Maximum Shared Folder Sync Tasks | 8 | |
| Hybrid Share Folder Number | 10 | |
| Synology High Availability | ||
| Syslog Events per Second | 800 | |
|
Virtualization |
VMware vSphere with VAAI | |
| Citrix Ready | ||
| OpenStack | ||
| Networking Protocols | SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV | |
| Supported Browsers |
|
|
| Supported Language | English, Deutsch, Français, Italiano, Español, Dansk, Norsk, Svenska, Nederlands, Русский, Polski, Magyar, Português do Brasil, Português Europeu, Türkçe, Český, ภาษาไทย, 日本語, 한국어, 繁體中文, 简体中文 | |
| Notes | For an updated list of supported browser versions, check the DSM Technical Specifications. | |
|
Add-on Packages view the complete package list |
||
|
Antivirus by McAfee (Trial) |
||
| Maximum Number of Concurrent Users | 100 | |
| Notes |
|
|
|
Document Viewer |
||
|
Download Station |
Maximum Concurrent Download Tasks | 80 |
| Maximum iSCSI Target Number | 128 | |
| Maximum LUN | 256 | |
| LUN Clone/Snapshot, Windows ODX | ||
| Free Email Accounts | 5 (Licenses required for additional accounts) | |
| Maximum Number of Concurrent Users | 100 | |
| Maximum Server Performance | 1,224,000 emails per day, approx. 37GB | |
| Notes |
|
|
| DLNA Compliance | ||
| Facial Recognition | ||
| Maximum Snapshots per Shared Folder | 1,024 | |
| Maximum of System Snapshots | 65,536 | |
| Maximum IP cam (Licenses required) | 40 (including 2 Free License) (see all supported IP cameras) | |
| Total FPS (H.264) |
1200 FPS @ 720p (1280×720) 800 FPS @ 1080p (1920×1080) 350 FPS @ 3M (2048×1536) 280 FPS @ 5M (2591×1944) 170 FPS @ 4K (3840×2160) |
|
| Total FPS (H.265) |
1200 FPS @ 720p (1280×720) 1200 FPS @ 1080p (1920×1080) 600 FPS @ 3M (2048×1536) 480 FPS @ 5M (2591×1944) 200 FPS @ 4K (3840×2160) |
|
| Notes |
|
|
| Recommended Number of Concurrent Sync Clients | 350 (the number of connections that can be maintained when the recommended number of hosted files was reached) | |
| Recommended Number of Hosted Files | 5,000,000 (applies to files indexed or hosted by Synology Drive. For file access through other standard protocols, refer to the File Services section above) | |
| Notes |
|
|
| Maximum Users | 1,200 | |
| Notes |
|
|
| Recommended Virtual Machine Instances | 4 (Learn more) | |
| Recommended Virtual DSM Number (Licenses required) | 4 (including 1 Free License) | |
| Notes | The specifications vary depending on system configuration and memory size. | |
| Maximum Connections | 40 | |
Notes:
- Model specifications are subject to change without prior notice.
- The figures are based on Synology internal testing. Each performance test is done individually. No other services or applications are processed at the same time.
- The actual performance may be lower than lab testing figure due to differences in server configuration, deployment, and the number of active operations.
- If usage requirements exceed the specifications above, please contact our regional partners for professional advice.
