Dual 10 and 2.5 Gigabit ports. Faster than ever.
The all new Lockerstor series of NAS feature dual Intel 10-Gigabit Ethernet ports as well as dual Realtek 2.5-Gigabit Ethernet ports. With a managed switch that supports multiple speeds, take advantage of up to 20 gbps of speed with both 10-Gigabit ports or up to 5 gbps on both 2.5-Gigabit ports.
Performance Figures
| 2x 10GbE LAGG Multiclient | 1x 10GbE Single Client | 2x 2.5GbE LAGG Multiclient | 1x 2.5GbE Single Client | ||
| Read | 1854 | 901 | 586 | 286 | |
| Write | 563 | 309 | 484 | 293 |
* Performance figures are achieved in the ASUSTOR lab using state of the art client computers under optimized network settings, and could vary in different environments. Ordinary desktop or notebook computers may be unable to reproduce these figures.
SSD Speeds for Hard Drive Prices – SSD Caching
The recently updated ADM features an updated Linux Kernel and additional performance enhancements. The Lockerstor series introduce M.2 PCIe NVMe SSD caching increasing performance.
1. Lockerstor NVMe SSD caching increases performance by up to 60%.
2. Lockerstor NVMe SSD caching is faster than if all bays were filled with SATA SSDs while remaining cheaper.
With dual 10-Gigabit Ethernet, bottlenecks on NVMe SSDs have been lifted, making the Lockerstor one of the fastest NAS devices ever.
Thumbscrews for easy M.2 SSD installation
Eight Bays with Flexible M.2 SSD Caching
The AS6508T is a cost-effective large capacity NAS designed for enterprise environments. The AS6508T supports online capacity expansion, allowing for the flexible purchase of enterprise storage equipment. When your budget and storage requirements are smaller, you can purchase a smaller number of hard disks. Additional disks can be purchased as your storage requirements grow. Combined with ASUSTOR’s MyArchive storage technology, this allows you to effectively achieve unlimited storage.
Powerful and high efficient cooling design
The Lockerstor utilizes PWM fans with smart speed controls and heatsinks with push-pin mounting to achieve optimal airflow, enhancing stability and maintaining high performance even under high loads.
The Lockerstor’s improved design features improved heatsinks that are taller than previous models to ensure even more efficient cooling and heat dissipation.
Easily upgrade memory by opening the chassis.
The Lockerstor comes with 8 Gigabytes of DDR4 RAM and can be upgraded up to 64GB. DDR4 RAM provides up to 30% greater performance than DDR3 while also lowering energy requirements by 40%.
24/7 Reliability and Durability
All ASUSTOR NAS are designed for and are suitable for 24/7 use. ASUSTOR NAS devices have also undergone rigorous tests, such as drop tests and burn tests to test durability in extreme conditions. Heatsinks were added to sensitive components to dissipate heat, helping to maintain the longevity of the device.
Protected From the Inside and Out
Protect your data from loss, damage and attacks with the ASUSTOR NAS. An ASUSTOR NAS is better protected by running the Linux-based ADM, employing a built-in firewall, ClamAV Antivirus, MyArchive and ADM’s various backup tools help protect ransomware even better.
Network Attack Protection
- Firewall
- ADM Defender
- Cloud Backup Center offsite backups
Secure Data Transmission
- VPN connection
- SSL certificate connection
- Automatic logout
Internal Data
- MyArchive on and offsite backups
- AES-256 folder encryption
- Antivirus software
Access Control
- File/folder/app isolation
- 2-Step Verification
- Wake-on-LAN (WOL)
- Wake-on-WAN (WAN)
Wake Up From Anywhere
The Lockerstor 8 and 10 feature Wake on WAN technology. No specialized equipment or settings are needed to wake the NAS. Simply use ASUSTOR’s wide variety of mobile apps, including but not limited to AiMaster, AiMusic, AiVideos and AiData to turn the NAS on or off remotely. Wake on WAN helps protect data by keeping the NAS powered off when not in use; thereby helping to prevent attacks, protects data integrity by remaining powered off during power failures and Wake on WAN also saves electricity, making for an even more efficient NAS.
Use mobile apps like AiMaster to power the NAS on or off.
- Helps prevent attacks and protect data.
- Power outage management
- Saves electricity
Protected From Ransomware
The Lockerstor comes with the most up-to-date version of ADM to help protect against ransomware attacks. With Snapshot Center and Btrfs providing efficient snapshots to easily restore lost data. Other security features found on the Lockerstor are the ability to create one or more replacement administrator accounts, a firewall by ADM Defender that features black and white lists and the ability to change default ports, disable SSH and Terminal to prevent remote attacks. MyArchive cold storage hard drive security can also be increased by implementing AES 256bit encryption.
Comprehensive Backup Solutions
ASUSTOR’s comprehensive backup solution provides more than twelve backup options, including, but not limited to Amazon S3, Dropbox, Google Drive, and OneDrive. ASUSTOR Backup Plan for Windows as well as Time Machine for macOS provide easy backups for desktop and laptops while MyArchive removable hard drives provide long term storage. Btrfs is now supported and with Snapshot Center, can take snapshots of your information in the event of unintentional modification. Restore previous versions easily with Snapshot Center.
Cross-Platform Multi-User Access
The ASUSTOR NAS provides seamless cross-platform and multi-user access, allowing you to easily connect to your NAS from Windows, macOS or Unix-like operating systems no matter if you are using a PC, notebook, tablet or smartphone.
- 4096 Accounts
- 512 Groups
- 512 Shared Folders
- 512 Concurrent Connections
Snapshot Center
Snapshot Center is a new feature for ASUSTOR NAS devices to utilize Btrfs and iSCSI volumes to take snapshots of the information inside a NAS. Snapshot Center supports up to 256 snapshots of a volume and can be done every five minutes, creating a backup that can be restored easily if data is damaged or lost.
ASUSTOR EZ Sync
ASUSTOR EZ Sync
- All new UI. Simpler and easier to operate. View NAS information quickly.
- More complete settings – offering detailed folder lists. Easily select folders and files not in a folder.
- Notifications for abnormal status
- Support 2-step verification increase account safety.
- Improve NAS connecting and file sync system stability for better user experience.
File Editing and Project Collaboration
Nextcloud and OnlyOffice make collaborating on projects easier than ever by creating a cloud office suite for offices to work on documents, spreadsheets, presentations and more.
Exclusive MyArchive Cold Backup Technology. Unlimited Capacity Expansion
MyArchive cold backup technology turns NAS hard disks into removable storage archives. Directly insert a MyArchive hard disk into the NAS to easily access, backup and share terabytes of content.
Virtual Applications with Virtualbox
Deploy all kinds of operating systems to your NAS.
ADM 3.5 brings a newer Linux Kernel, providing better system security and stability.
Portainer – Easy Docker Deployments
Even more possibilities for ADM with Portainer for Docker images. With thousands of images, Portainer can download and deploy more types of programs than ever before. Portainer is incredibly user friendly and employs a graphical interface to make docker images easier to deploy than ever.
Comprehensive Surveillance System
An ASUSTOR NAS provides optimal reliability for home and small business users looking to set up a surveillance system. Four free camera channels are offered, making it an extremely cost-effective surveillance solution for those looking to protect their home or small business. ASUSTOR provides each NAS with the capability to expand to more cameras for those with bigger demands. Up to 64 camera channels can be purchased through camera licenses. After installing Surveillance Center and its corresponding mobile app AiSecure, stream live surveillance feeds to virtually any internet-connected Android or iOS smartphone to keep an eye on your most valued assets from anywhere, inside or outside.
ASUSTOR Live
Your own streaming center. Stream your from a phone or tablet as well as a computer to multiple streaming platforms, Including, but not limited to Twitch, YouTube, Facebook, Instagram, Restream or RTMP compatible platforms. Unlike services like restream.io, ASUSTOR Live doesn’t require fees to operate to stream to multiple platforms and channels which saves you money and streaming resources. Recordings can be safely saved to your NAS for future use.
Enterprise Versatility
ASUSTOR NAS offers rich variety of services for business users. For the price of one NAS you can create a multifunctional server that is worth much more.
App Central
Unleash the unlimited potential of an ASUSTOR NAS. The applications that come pre-installed with each ASUSTOR NAS device are just the beginning. At your convenience, browse through and download any applications that pique your interest from App Central. Whether your interests lie in business, website construction or digital home entertainment, App Central has you covered. With over 200 unique apps, App Central provides you with a virtually boundless variety of applications that to satisfy your digital lifestyle needs. Explore the virtually unlimited potential of your ASUSTOR NAS while creating a personalized experience for yourself.
Mobile Apps
ASUSTOR’s exclusive EZ-Connect technology allows you to connect to your NAS from anywhere with your Android or iOS device to securely access, download, upload and share files and information. ASUSTOR mobile apps securely protect your privacy and data by requiring passwords in order to protect your privacy and data. You can also make use of HTTPS connections for even more added security.
First-Class Product Warranty
All ASUSTOR NAS products come with a 3-year warranty. ASUSTOR continues to make customer service a priority in providing the highest standard of after-sales service and technical support.
Hardware Specifications
CPU
- CPU Model: Intel ATOM C3538
- CPU Architecture: x64 64-bit
- CPU Frequency: Quad-Core 2.1GHz
Memory
- Memory: 8GB SO-DIMM DDR4 Compatibility
- Memory Module Pre-installed: 8GB (1 x 8GB)
- Total Memory Slots: 2
- Memory Expandable up to: 64GB (2 x 32GB) Installation Guide
- Support mixed capacity
- Flash Memory: 4GB eMMC
Storage
- Drive Bays: 8
- M.2 Drive Slots: 2 Installation Guide
- Compatible Drive Type Compatibility:
- 3.5″ SATA HDD
- 2.5″ SATA HDD
- 2.5″ SATA SSD
- M.2 2280 NVMe
- M.2 2280 SATA 3
- M.2 2260 SATA 3
- M.2 2242 SATA 3
- M.2 PCIe Interface: PCIe 3.0 x2
- Maximum Drive Bays with Expansion Unit: 16
- Supports Hot Swappable Drives
External Ports
- Expansion:
- 2 x USB 3.2 Gen 1
- Network:
- 2 x 10 Gigabit Ethernet (10G/1G)
- 2 x 2.5 Gigabit Ethernet (2.5G/1G/100M)
- Multimedia Output: N/A
Others
- System Fan: 2 x 120mm
- LCD Panel
- Power Supply Unit / Adapter: 250W x1
- Input Power Voltage: 100V to 240V AC
- Certification: FCC, CE, VCCI, BSMI, C-TICK
- Warranty: 3 Years
Operation
- Power Consumption:
- 66.9W (Operation)
- 37.2W (Disk Hibernation)
- Noise Level: 22dB (HDD idle)
- Operation Temperature: 0°C~40°C (32°F~104°F)
- Storage Temperature: -20°C~70°C (-4°F~158°F)
- Humidity: 5% to 95% RH
Size and Weight
- Size: 215.5(H) x 293(W) x 230(D) mm
- Weight: 6.2 (kg) / 13.67 (lb) Package Contents
Software & Features
General Specifications
- Supported OS:
- Windows 10, 11, Server 2016, Server 2019, Server 2022
- macOS
- UNIX, Linux, and BSD
- Supported Languages: Deutsch, English, Français, Italiano, Nederlands, Русский, 日本語, 한글, 简体中文, 繁體中文, Česká, Polski, Svenska, Dansk, Norsk, Suomi, Português, Türkçe, Español, Magyar, ภาษาไทย
- Supported Browsers:
- Firefox
- Chrome
- Safari
- Microsoft Edge
Network
- Network Protocols: CIFS / SMB, SMB 2.0 / 3.0, AFP, NFS, FTP (Unicode Supported), TFTP, WebDAV, Rsync, SSH, SFTP, iSCSI/IP-SAN, HTTP, HTTPS, Proxy, SNMP, Syslog
- Connection and transmission:
- TCP/IP (IPv4 & IPv6)
- Link Aggregation: Supports 802.3ad and Six Other Modes for Load Balancing and/or Network Failover
- Jumbo Frame (MTU)
- VLAN
- EZ Connect
- Wireless Network
- DDNS and EZ-Router Compatibility
- 2.5 GbE Supports Wake-on-LAN (WOL) See More
- 2.5 GbE Supports Wake-on-WAN (WOW) See More
File Management & Sharing
- File System:
- Internal Disk: EXT4, Btrfs
- External Disk: FAT32, NTFS, EXT3, EXT4, HFS+, exFAT, Btrfs
- File Explorer:
- Web-based File Management
- ISO File Mounting
- Share Links
- Task Monitor
- Browse Files on Local PC
- Thumbnail Previews
- Data Access via External Optical Drive
- Supports video playback
- Network Recycle Bin:
- Share folder-based
- Maintains original directory structure and file permission
- On-click restore
- Supports scheduled emptying
- Filtering rules
- File size
- File extension
- Deletion Settings
- File size
- File date
Storage Management
- Supported RAID levels:
- Single
- JBOD
- RAID 0
- RAID 1
- RAID 5
- RAID 6
- RAID 10
- Supported RAID migration methods:
- Single to RAID 1
- Single to RAID 5
- Single to RAID 6
- Single to RAID 10
- RAID 1 to RAID 5
- RAID 1 to RAID 6
- RAID 1 to RAID 10
- RAID 5 to RAID 6
- Volume:
- RAID levels supporting storage expansion by complete drive replacement:
- RAID 1
- RAID 5
- RAID 6
- RAID 10
- RAID levels supporting storage expansion by drive addition:
- RAID 5
- RAID 6
- RAID 10
- RAID spare drive support:
- RAID 1
- RAID 5
- RAID 6
- RAID 10
- Supported RAID levels:
- Single
- JBOD
- RAID 0
- RAID 1
- Supported RAID migration methods:
- Single to RAID 1
- RAID levels supporting storage expansion by complete drive replacement:
- M.2 Volume:
- RAID levels supporting storage expansion by complete drive replacement:
- RAID 1
- RAID levels supporting storage expansion by drive addition: –
- Supported RAID migration methods: –
- RAID levels supporting storage expansion by complete drive replacement:
- MyArchive:
- Hot swappable design enables easy transfer or exchange of high amounts of data
- Works on any empty bay on an ASUSTOR NAS
- File system support: EXT4, NTFS, HFS+, Btrfs and exFAT
- Supports AES 256-bit encryption on EXT4 and Btrfs
- Supports Btrfs snapshots
- Supports decryption with a USB key
- iSCSI/IP-SAN:
- Maximum Targets: 256
- Maximum LUNs: 256
- Maximum Snapshot Versions of a Single LUN: 256
- Target Masking
- LUN Mapping
- ISO File Mounting
- Supports MPIO
- Persistent (SCSI-3) Reservations
- Disk Management:
- Scheduled Bad Block Scans
- Scheduled S.M.A.R.T Scans
Access & Security
- Access Control:
- Maximum Number of Users: 4096
- Maximum Number of Groups: 512
- Maximum Number of Shared Folders: 512
- Maximum Number of Concurrent Connections: 512
- Supports Windows Active Directory
- Supports Windows Active Directory / LDAP
- ACL:
- Provides both Windows ACL and Linux ACL permission configuration methods
- Can enable Windows ACL for specific shared folders
- Comprehensive support for Windows’ 13 types of advanced permission settings
- Can view Windows ACL permission settings from within ADM
- Supports local users and groups
- Exclusive permission reset function allows users to quickly restore default permissions
- SSD Cache:
- SSD-like performance with traditional hard drives
- Supports read-only access and read-write cache mode
- System Administration:
- Log Type: System Log, Connection Log, File Access Log
- Real-time Online User Monitor
- Real-time System Monitor
- User Quota
- Virtual Drive (ISO Mounting, Maximum 16)
- UPS Support Compatibility
- Security:
- AES 256-Bit Encryption
- Firewall: Prevent Unauthorized Access
- Alert Notifications: E-mail, SMS
- Encrypted Connections: HTTPS, FTP over SSL/TLS, SSH, SFTP, Rsync over SSH
- Built-in Hardware Encryption Engine
- RAID Scrubbing: detects the integrity and consistency of RAID 5 and RAID 6 drive data.
- Network Defender:
- Auto black list
- Trusted list
- Black/White list
- Supports IP/IP range/geolocation
Backup
- Backup Solutions:
- Rsync (Remote Sync) Backup
- Cloud Backup
- FTP Backup
- External Backup
- One Touch Backup
- EZ Sync
- SMB Backup
- Snapshots:
- Btrfs Snapshots
- 256 Snapshots
- iSCSI LUNs
Others
- ASUSTOR Hightlight:
- System Migration
- EZ Connect
- Dr. ASUSTOR
- 2-way Backup
- Task Monitor
- Eco-Friendly Design:
- Auto-Standby for Both Internal and External Disks
- Auto Fan Control
- LED Night Mode
- Power Schedule: On, Off, Restart
- Energy Control:
- Configurable Disk Hibernation Wait Time
