AVer UE1 USB Extender is a professional-grade extension solution designed to overcome traditional distance limitations for PTZ cameras and AV equipment. By transmitting USB 3.0, HDMI, and control data over standard network cables, the UE1 ensures high-bandwidth, uncompressed signals reach up to 100 meters (328 feet) without degradation. With support for 4K 60fps resolution, PoE++ capability, and seamless UVC/UAC compatibility, the UE1 provides a reliable, plug-and-play infrastructure for classrooms, corporate boardrooms, and large-scale hybrid environments.

KEY FEATURES

• Long-Distance Extension: Transmits USB 3.0, HDMI, and control data up to 100 meters (328 feet) over standard CAT5e, CAT6, or CAT7 cables
• 4K 60fps Support: Delivers crisp, high-resolution video and audio output via both USB and HDMI connections without signal loss
• PoE++ Compatible: Simplifies installation and reduces cable clutter by supporting Power over Ethernet (PoE++) for single-cable power and data transmission
• Seamless Plug-and-Play: Fully compatible with USB Video Class (UVC) and USB Audio Class (UAC) protocols, requiring no additional drivers or software
• Flexible Mounting Options: Includes a DIN rail mounting clip and cable management accessories for secure, professional installation in AV racks or behind displays
• Broad Device Compatibility: Specifically optimized for AVer PTZ cameras and a wide range of professional USB audio/video peripherals

SPECIFICATIONS

• Input Interfaces: 1x USB 3.0 Type-B, 1x RJ-45 (LAN)
• Output Interfaces: 1x USB 3.0 Type-A, 1x RJ-45 (LAN), 1x HDMI
• Transmission Distance: Up to 100 meters (328 feet)
• Cable Support: CAT5e, CAT6, CAT7
• Output Resolution: Up to 4K at 60fps (via USB and HDMI)
• Supported Protocols: USB 3.0, USB Video Class (UVC), USB Audio Class (UAC)
• Power Supply: PoE++ (Power over Ethernet) or included DC power adapter
• Operating Environment: Temperature: 0°C to 40°C (32°F to 104°F) | Humidity: 20% to 80% (non-condensing)
• Mounting: Desktop, wall-mount, and DIN rail mount compatible

WHAT’S IN THE BOX

• 1x AVer UE1 USB Extender Kit (Transmitter and Receiver units)
• 1x Power Adapter & Power Cord
• 1x USB 3.0 Type-A to Type-B Cable
• 1x DIN Rail Mounting Clip
• 1x Cable Fixing Plate
• 3x Cable Ties
• 4x M3 x 5.1 mm Mounting Screws
• 1x Quick Start Guide
