Description

Benefits

Rich visual Experience

The C63G/C63GP is an entry-level IP phone, and the C63G/C63GP features a 2.8″ high-resolution color TFT display with backlight, which takes visual effects to a new level. The freely programmable multi-color function keys provide users with a high degree of usability. Each function key can be configured for various one-touch phone functions such as speed dial, busy lamp field, etc.

High Quality Audio

The full duplex speaker and microphone system and the Digital Signal Processor (DSP) ensure that the C63G/C63GP delivers high audio quality. Whether you use the hands-free speakerphone or the handset, you will always have good experience and crystal-clear call quality

Good Compatibility

Based on RFC3261, the C63G/C63GP has been tested to ensure good compatibility with leading IP telephony system and equipments. The C63G/C63GP not only supports Dinstar UC/IPPBX products, also supports many third-party IPPBXs such as 3CX, Asterisk, Yeastar, Xorcom, VoIP.ms and so on.

Specifications

Call Features

• 16 SIP Accounts
• Call Waiting
• Call Forward
• Blind/attended transfer
• Call hold, Call mute, DND mode
• Speed Dialing, Hotline
• Redial, Call Return
• Auto-redial, Auto-answer
• Dial Plan
• 5-way conference
• Peer Dialing IP-PBX Features
• SMS, Voicemail, MWI
• Music On-hold, Intercom, Multicast
• Call Pickup, Call Pickup in Group
• Anonymous Call
• Anonymous Call Rejection

Phone Features

• Adjustable Voice Volume
• Selectable Ring Tones
• XML Browser
• Action URL/URI
• Keyboard lock
• Phonebook: 1,000 Groups
• Blacklist: 100 Groups
• Call Log: 100 Logs
• Support 5 Remote Phonebook URLs
• LDAP
• Support Multiple Languages
• Support EHS wireless headset(Plantronics, Jabra, Sennheiser)

IP-PBX Features

• SMS, Voicemail, MWI
• Music On-hold, Intercom, Multicast
• Call Pickup, Call Pickup in Group
• Anonymous Call
• Anonymous Call Rejection

Management

• Auto provisioning: FTP/TFTP/HTTP/HTTPS/PnP
• Configuration via HTTP/HTTPS web
• SNMP, TR069
• Network capture
• NTP/Daylight saving time
• Firmware upgrade via web
• Syslog
• Configuration backup/restore
• Equipment Management System (NMS）

Audio

• HD Voice
• Wideband Codec: G.722, OPUS-WB
• Narrowband Codec: PCMA, PCMU, G.729, G723, G726, AMR, OPUS, iLBC
• Echo Cancellation/Dynamic Jitter
• Voice Activity Detection (VAD)
• Comfort Noise Generation (CNG)
• Full-duplex Speaker

Protocols & Standards

• SIP v1 (RFC2543), SIP v2 (RFC3261)
• SIP over TLS, SRTP
• TCP/IP/UDP
• RTP/RTCP, RFC2198, RFC1889
• HTTP/HTTPS/FTP/TFTP
• ARP/RARP/ICMP/NTP/DHCP
• DNS SRV/ A Query/NATPR Query
• STUN, Session Timer (RFC4028)
• DTMF: In-Band, RFC2833, SIP INFO
• LLDP
• OpenVPN, 802.1X

Physical Features

• Color 2.8” High resolution screen (240×320)
• Dimensions(approx.): 201x203x42.5mm(WxLxD) without foot stand
• Weight(approx.): device 550g, foot stand 50g
• Input voltage: 5Vdc
• Power supply: 5Vdc power adapter or PoE
• Power consumption: 1.8W
• PoE IEEE802.3af
• Handset: 4P4C, RJ9
• Headset: 4P4C, RJ9
• Extended interface: 6P6C, RJ12
• Environmental conditions: Operation temperature: 0~40°C Humidity: 10% to 95% (non-condensing)
• 2xRJ45 10/100/1000M Ethernet Ports
• Wall Mountable
