OVERVIEW

Higher resolution quality

• Sharper text and vivid images
• Includes more information on the screen
• Better audience engagement

Bigger projections

When you are looking for bigger display, projection is the obvious answer ensuring that your information is conveyed clearly and accurately for everyone in the room.

Split Screen Function for Wired / Non-wired Devices

A split screen function enables the simultaneous projection of two images from separate devices through both wired and wireless connections on a single screen, eliminating the need for a second projector. Classroom lessons and business meetings can now be more engaging by connecting the projector with a document camera and a PC or tablet.

Various Interfaces

Epson business projectors support a wide range of connectivity options including HDMI, VGA, and USB. These interfaces support connections to both the latest digital devices as well as the existing legacy of analogue products without the need for adaptors.


SPECIFICATIONS

PROJECTION TECHNOLOGY:

Projection Technology:RGB liquid crystal shutter projection system (3LCD)


BRIGHTNESS2:

White Light Output (Normal/Eco):3,600 lm
Colour Light Output:3,600 lm


CONNECTIVITY:

USB Interface:
USB Type A: 1 (For Wireless LAN, Firmware Update, Copy OSD Settings)
USB Type B: 1 (For Firmware Update, Copy OSD Settings)

Network:Wireless: Optional (ELPAP11)

Analog Input:
Composite: 1 RCA
D-Sub 15pin: 1

Digital Input:
HDMI: 1 (MHL not supported)

Audio Input:2 RCA: 1


CONTRAST RATIO:

Contrast Ratio: 16,000:1


SCREEN SIZE (PROJECTED DISTANCE):

Standard Size:Tele: 30” to 300” [1.07 to 10.95 m]
Wide: 30” to 300” [0.89 to 9.12 m]


GEOMETRIC CORRECTION:

Vertical/Horizontal Keystone:±30° / ±30° (Auto Vertical Keystone only)
Quick Corner:Yes


OPERATING TEMPERATURE:

Operating Temperature:
Low Altitude: 5 – 40 °C <41 – 104 °F>
High Altitude: 5 – 35 °C <41 – 95 °F>
(20% – 80% Humidity, No Condensation)


OPERATING ALTITUDE:

Operating Altitude:0 – 3,048 m <0 – 10,000 ft>


START-UP PERIOD:

Start-Up Period:Up to 6 seconds, Warm-up Period: 30 seconds


COOL DOWN PERIOD:

Cool Down Period:Instant Off


DIRECT POWER ON/OFF:

Direct Power On/Off:Yes


DIMENSION EXCLUDING FEET (W X H X D):

Dimension Excluding Feet (W x H x D):302 x 77 x 234 mm


WEIGHT:

Weight:Approx. 2.5 kg


AIR FILTER:

Type:High Efficiency Filter
Maintenance Cycle:6,000 / 12,000 hours*3


FAN NOISE:

Fan Noise (Normal / Eco): 37dB / 28dB


POWER:

Power Supply Voltage: 100 – 240 V AC ±10%, 50/60 Hz


PROJECTORS FACETS:

Resolution, Projectors Facets:XGA
Contrast Ratio, Projectors Facets:16,000:1
Brightness Range Lumens, Projectors Facets:2000
Features, Projectors Facets:Wifi Quick Corner
Laser / Lamp, Projectors Facets:Lamp


OPTIONAL WIRELESS & BUILT IN LAN SPECIFICATIONS:

Supported Speed for each Mode:
IEEE 802.11b (2.4GHz): 11 Mbps*2
IEEE 802.11g (2.4GHz): 54 Mbps*2
IEEE 802.11n (2.4GHz): 72.2 Mbps*2
IEEE 802.11a (5GHz): 54Mbps*2
IEEE 802.11n (5GHz): 150 Mbps*2

Wireless LAN Security:
Infrastructure: OPEN, WPA2/WPA3-PSK
Access Point: OPEN, WPA2-PSK (AES)


SPECIFICATIONS OF MAIN PARTS:

LCD:
Native Resolution: XGA (1024 x 768)
Size: 0.55” (C2fine)

Lightsource:
Type: 210W UHE
Life (Normal / Eco): 6,000 / 12,000 hours

Aspect Ratio:
4:3

Projection Lens:
F-Number: 1.49 – 1.72
Type: Optical Zoom (Manual) / Focus (Manual)
Focal Length: 16.90 – 20.28 mm
Zoom Ratio: 1 – 1.2
Throw Ratio1.48 – 1.77 (Wide to Tele)
