Technical Specifications

• Switching Capacity: 60 Gbps
• Packet Forwarding Rate: 44.6 Mpps
• GE RJ45 Ports:
  • 8 × GE RJ45 (1G/100M/10M)
• GE SFP Ports:
  • 2 × GE SFP (1G/100M)
• 10GE SFP+ Ports:
  • 2 × 10GE SFP+ (10G/1G)
• Certification:
  • EMC certification
  • Safety certification
  • Manufacturing certification
• Chassis Material: Metal
• Dimensions (H × W × D):
  • Basic dimensions (excluding the parts protruding from the body): 150.0 mm × 44.0 mm × 133.0 mm (5.91 in. × 1.73 in. × 5.24 in.)
  • Maximum dimensions (depth measured from front-panel ports to the parts protruding from the rear panel): 162.0 mm × 44.0 mm × 142.0 mm (6.38 in. × 1.73 in. × 5.59 in.)
  • With packaging: 113.0 mm × 235.0 mm × 188.0 mm (4.45 in. × 9.25 in. × 7.40 in.)
• Installation Type: Rack mounting / DIN rail
• Weight: 0.975 kg (without packaging) / 1.34 kg (with packaging)
• Static Power Consumption: 5.64 W
• Typical Power Consumption: 12.48 W
• Maximum Power Consumption:
  • 16.2 W @ 60 V
  • 13.2 W @ 12 V
• Long-Term Operating Temperature:
  • Altitude: 0–1800 m (0–5906 ft.)
  • Industrial optical modules:
    • Sealed cabinet: –40°C to +65°C (–40°F to +149°F)
    • Vented cabinet (≥ 40 LFM): –40°C to +70°C (–40°F to +158°F)
    • Blower-equipped cabinet (≥ 200 LFM): –40°C to +75°C (–40°F to +167°F)
• Long-Term Operating Relative Humidity [RH]: 5% RH to 95% RH, non-condensing
• Power Supply Mode: DC external
• Input Voltage Range:
  • DC input: 9.6 V DC to 60 V DC
• Power Supply Surge Protection:
  • DC power: ±2 kV in common mode and ±1 kV in differential mode
• Heat Dissipation Mode: Natural heat dissipation
• Chassis Height: 3.65 U
• Redundant Power Supply: 1+1
• Service Port Surge Protection:
  • Common mode: ±6 kV
