Description
Technical Specifications
- Switching Capacity: 36 Gbit/s
- Packet Forwarding Rate: 26.78 Mpps
- GE RJ45 Ports:
- 16 × GE RJ45 (PoE+) (1G/100M/10M)
- PoE: Supported
- Maximum PoE Power Consumption: 124 W
- Dimensions (H × W × D):
- Basic dimensions (excluding the parts protruding from the body): 43.6 mm × 442.0 mm × 260.0 mm (1.72 in. × 17.40 in. × 10.24 in.)
- Maximum dimensions (depth measured from front-panel ports to the parts protruding from the rear panel): 43.6 mm × 442.0 mm × 267.0 mm (1.72 in. × 17.40 in. × 10.51 in.)
- With packaging: 90.0 mm × 555.0 mm × 400.0 mm (3.54 in. × 21.85 in. × 15.75 in.)
- Installation Type: Rack mounting / Desk mounting / Wall mounting
- Weight: 3.0 kg (6.61 lb) without packaging / 3.7 kg (8.16 lb) with packaging
- Maximum Power Consumption:
- Without PoE: 22.0 W
- Full PoE load: 160.0 W (PoE: 124 W)
- Power Supply Mode: AC built-in
- Input Voltage Range:
- AC input: 90 V AC to 300 V AC; 47 Hz to 63 Hz
