Description
Technical Specifications
- Switching Capacity: 200 Gbit/s
- Packet Forwarding Rate: 144 Mpps
- 2.5GE RJ45 Ports:
- 24 × 2.5GE RJ45 (PoE+) (2.5G/1G/100M/10M)
- 10G SFP+ Ports:
- 4 × 10G SFP+ (10G/1G)
- PoE: Supported
- Maximum PoE Power Consumption: 400 W
- iStack: Supports up to 4 switches of the same series in a stack
- Certification:
- EMC certification
- Safety certification
- Manufacturing certification
- Chassis Material: Metal
- Dimensions (H × W × D):
- Basic dimensions (excluding the parts protruding from the body): 43.6 mm × 442.0 mm × 420.0 mm (1.72 in. × 17.4 in. × 16.54 in.)
- Maximum dimensions (depth measured from front-panel ports to the parts protruding from the rear panel): 43.6 mm × 442.0 mm × 446.0 mm (1.72 in. × 17.4 in. × 17.56 in.)
- With packaging: 185.0 mm × 650.0 mm × 550.0 mm (7.28 in. × 25.59 in. × 21.65 in.)
- Installation Type: Rack mounting / Desk mounting
- Weight: 4.71 kg (10.38 lb) without packaging / 6.89 kg (15.19 lb) with packaging
- Static Power Consumption: 37.1 W
- Typical Power Consumption: 54.8 W
- Maximum Power Consumption:
- Without PoE: 77.70 W
- Full PoE load: 517.30 W (PoE: 400 W)
- Number of Fan Modules: 2
- Long-Term Operating Temperature:
- –5°C to +45°C (23°F to 113°F) at an altitude of 0 to 1800 m (0 to 5905.44 ft.)
- Long-Term Operating Relative Humidity [RH]: 5% RH to 95% RH, non-condensing
- Power Supply Mode: AC built-in
- Input Voltage Range:
- AC input: 90 V AC to 290 V AC; 45 Hz to 65 Hz
- High-voltage DC input: 190 V DC to 290 V DC
- Power Supply Surge Protection:
- Differential mode: ±6 kV
- Common mode: ±6 kV
- Types of Fans: Built-in
- Heat Dissipation Mode: Air cooling for heat dissipation with intelligent fan speed adjustment
- Airflow Direction: Air intake from the left and front, with air exhaust from the right
