Description

Hardware Specifications

Port Specifications
Number of 10/100/1000BASE-T ports : 5
Number of fixed LAN ports : 1
Number of fixed WAN ports : 1

System Specifications
CPU : Dual-core processor, 1.3 GHz clock frequency
Flash memory : 128 MB SPI NAND Flash
RAM : 512 MB DDR3

Wi-Fi Radio
Wi-Fi standard : Wi-Fi 6 (IEEE 802.11ax) standard, compatible with IEEE 802.11a/b/g/n/ac standards
Maximum wireless data rate : 2974 Mbps

Dimensions and Weight
Product dimensions (W x D x H) : 283 mm x 172 mm x 46 mm (11.14 in. x 6.77 in. x 1.81 in.) (excluding the antennas and foot pads)
Weight : 1.2 kg (2.65 lbs.) (without packaging materials)

Environment and Reliability
Mounting options : Desk
Operating temperature : 0°C to 40°C (32°F to 104°F)

Software Specifications

System Performance Capacity
Recommended number of concurrent clients : 160
Throughput : 1200 Mbps
