Description
Hardware Specifications
Port Specifications
Number of 10/100/1000BASE-T ports : 10
Number of fixed LAN ports : 6
Number of fixed WAN ports : 1
System Specifications
CPU : Dual-core processor, 1.35 GHz clock frequency per core
Flash memory : 256 MB
RAM : 512 MB
Dimensions and Weight
Product dimensions (W x D x H) : 440 mm x 200 mm x 43.6 mm (17.32 in. x 7.87 in. x 1.72 in.)
Weight : 2.4 kg (5.29 lbs)
Environment and Reliability
Mounting options : Rack
Note: The device occupies 1 U of the rack space.
Operating temperature : 0°C to 40°C (32°F to 104°F)
Software Specifications
System Performance Capacity
Recommended number of concurrent clients : 350
Throughput : 1500 Mbps
