Product Information

• Product Category: Layer 2

Hardware Specifications

• Warranty: 5 years

Port Specifications

• Total RJ45 Ports: 24
• Total Optical Ports: 4
• 1GE Combo Ports: No
• 1GE SFP Ports: 4
• 10GE SFP+ Ports: No
• 10/100BASE-T Ports: No
• 10/100/1000BASE-T Ports: 24
• 10/100/1000/2500BASE-T Ports: No
• 100/1000/2.5G/5G/10GBASE-T Ports: No

System Specifications

• Forwarding Rate: 41.66 Mpps
• Switching Capacity: 56 Gbps

Environment and Reliability

• MTBF: 400,000 hours
• Operating Temperature: 0°C to +50°C (32°F to 122°F)
• Altitude:
  • Operating: -500 m to +5,000 m
  • Storage: -500 m to +5,000 m
• Surge Protection:
  • Service Port: ±6 kV (common mode)
  • Power Connector: ±6 kV (common mode), ±6 kV (differential mode)

Software Specifications

• PoE Watchdog: No
• Jumbo Frame (MTU): 9216 bytes
• Port Isolation: Yes
• Broadcast Storm Control: Yes

Order Information

• Device: RG-NBS3100-24GT4SFP-V2
• Mounting Bracket: 2
• Foot Pad: 4
• Power Supply: Power cord
• Quick Start Guide: 1
• Warranty Card: 1
• Accessories: Screws × 6
• Package Weight: 2.4 kg
• Package Dimension: 533 × 258 × 102 mm
