Description

Product Information

Product Category
Product Category : Layer 2

Hardware Specifications

Product Information
Warranty : 5 years

Port Specifications
Total number of RJ45 ports : 8
Total number of optical ports : 2
Number of 1GE combo ports : No
Number of 1GE SFP ports : 2
Number of 10GE SFP+ ports : No
Number of 10/100BASE-T ports : No
Number of 10/100/1000BASE-T ports : 8
Number of 10/100/1000/2500BASE-T ports : No
Number of 100/1000/2.5G/5G/10GBASE-T ports : No

Power Supply and Consumption
Number of PoE Out ports : 8
Number of PoE/PoE+ Out ports : 8
Number of PoE/PoE+/PoE++ Out ports : No
PoE budget : 125 W
PoE power pins : 1–2 (+), 3–6 (-)

System Specifications
Forwarding rate : 14.88 Mpps
Switching capacity : 20 Gbps(bit/s)

Environment and Reliability
MTBF : 400,000 hours
Operating temperature : 0°C to +50°C (32°F to 122°F)

Altitude :

Operating altitude: –500 m to +5,000 m (–1,640.42 ft. to +16,404.20 ft.)
Storage altitude: –500 m to +5,000 m (–1,640.42 ft. to +16,404.20 ft.)

Surge protection :

Service port: ±6 kV for common mode
Power connector: ±6 kV for both common mode and differential mode

Software Specifications

Basic Configurations
PoE watchdog : Yes

Interface
Jumbo frame length (MTU) : 9216 bytes (global configuration mode)

Security
Port isolation : Yes
Broadcast storm control : Yes
