Description
Product Information
Product Type
Product Type : Wall AP
Hardware Specifications
Wi-Fi Radio
Radio design :
Dual-radio
4 spatial streams
● 2.4 GHz: 2 x 2, MU-MIMO
● 5 GHz: 2 x 2, MU-MIMO
Maximum wireless data rate : 2974 Mbps
6 GHz wireless data rate : No
5 GHz wireless data rate : 2401 Mbps
2.4 GHz wireless data rate : 573 Mbps
Antenna
Antenna :
5 GHz: 1 built-in omnidirectional antenna
Integrated 2.4 GHz and 5 GHz: 2 built-in omnidirectional antennas
Dimensions and Weight
Product dimensions (W x D x H) : 86 mm x 24 mm x 124 mm (3.39 in. x 0.94 in. x 4.88 in.) (excluding the mounting bracket)
Color : White
Weight : ≤ 0.26 kg (0.57 lbs.) (without packaging materials)
Port Specifications
Number of 10/100/1000BASE-T ports : 5
Power Supply and Consumption
Power supply : PoE/PoE+
Local power supply : No
Dimensions of the DC connector : No
PoE budget : No
Maximum power consumption : 12 W
Environment and Reliability
Operating temperature : 0°C to 40°C (32°F to 104°F)
Mounting options : Junction box
IP rating : IP41
Software Specifications
WLAN
Maximum number of associated wireless clients :
64 (2.4 GHz)
256 (5 GHz)
256 (2.4 GHz and 5 GHz enabled)
Maximum number of devices that can be managed : 300
IP Service
IPv6 : Yes
