LARK SPK6 Active Speaker is a professional sound reinforcement speaker specially tuned for classroom environments, featuring an integrated design where the main speaker drives the sub-speaker without the need for additional amplifier equipment. The built-in amplifier module offers independent volume adjustment, a 3-pin Phoenix terminal for mono balanced input, and RCA stereo input. Equipped with built-in DSP optimization to ensure exceptional voice clarity, the amplifier module also includes comprehensive protection circuits against overload, short circuits, and overheating, making it a reliable, efficient, and easy-to-install audio solution for educational and commercial spaces.

KEY FEATURES

• Integrated Class D Amplifier: Features a highly efficient and energy-saving Class D digital amplifier, eliminating the need for external amplification equipment
• Main-Sub Speaker Design: The main box can directly drive the sub-speaker via dedicated speaker output terminals, simplifying system setup and reducing hardware costs
• Built-in DSP Optimization: Incorporates DSP processing to ensure crystal-clear voice reproduction, specifically tuned for classroom and speech reinforcement applications
• Comprehensive Protection Circuits: Built-in overload, short circuit, and overheating protection ensures safe and reliable operation in demanding environments
• Flexible Audio Inputs: Equipped with a 3-pin Phoenix terminal for mono balanced input and RCA connectors for stereo input, accommodating various source devices
• Wall-Mountable & Compact Design: Stylish form factor designed for easy wall mounting, saving valuable floor space while providing a DC 12V output for auxiliary devices

SPECIFICATIONS

• Tweeter: 1x 20mm voice coil tweeter
• Woofer: 1x 6-inch, 25mm voice coil
• Power Rating: 60W
• Frequency Response (-10dB): 100Hz – 20kHz
• Sensitivity (1W/1M): 90dB
• Maximum Sound Pressure Level: 108dB (114dB Peak)
• Impedance: 4Ω
• Audio Input Interfaces: 3-pin Phoenix terminal (balanced mono input), RCA (stereo input)
• Audio Output Interfaces: Speaker terminal block (for sub-speaker connection), DC 12V output
• Power Supply: AC 220V / 50Hz
• Speaker Dimensions (H×W×D): 300mm × 220mm × 150mm
• Package Dimensions (H×W×D): 430mm × 280mm × 365mm
• Weight: 8.5kg / Pair

WHAT’S IN THE BOX

• 1x Pair of LARK SPK6 Active Speakers (Main & Sub)
• 1x Power Cable
• 1x Quick Start Guide
• 1x Warranty Card
