Description

Tenveo Vloop 12U is equipped with, POE, USB3.0, Sony Sensor, truly 4K Lens, 12X optical zoom, and an Ultra-HD image system. It delivers sharp video, outstanding color, and exceptional optical accuracy. Its built-in AI technology optimizes light balance to emphasize faces and render natural-looking skin tones even in dim or backlighting conditions. In addition, 12X optical zoom with Wide Horizontal Angle enables VLoop 12U to easily meet the needs of medium to large-sized meeting rooms.

Product Features

4K Ultra HD, extraordinary clear and realistic video conferencing experience

Tenveo VLoop 12U adopts Sony IMX415 1/2.8″ CMOS Sensor and 4K Ultra HD imaging system. That’s why even on large-screen TVs, images delivered by it are still realistic, not pixelated. 4K, 8.29 megapixel and Sony Sensor help you enjoy high-quality video conferences and further enhance team collaboration.

12X Optical Zoom, more image details without losing quality

With 12X optical zoom, Tenveo Vloop 12U delivers you a video image filled with details. Even if you zoom in to examine the details, the image is as seen by eyes without distortion.

Multiple-interface, more flexible personalized options for you

Aligning with USB3.0, HDMI, and RJ45, Tenveo Vloop 12U brings great flexibility to video conferencing options. USB 3.0 output offers a transfer rate that is 10 times faster than USB2.0, so this camera could greatly improve the meeting experience and avoid video freezes. If you want to use large-screen TVs, the VLoop 12U also has HDMI ports for you to choose.

Zero-latency and perfect for online live-streaming (RTMP, RTSP)

The RJ45 output of the Vloop 12U supports not only video live streaming via RTMP, RTSP protocol, but also PoE function. Remote conferencing can be realized quickly with just one Ethernet cable. Get rid of troubles of tangled cables and help to improve your work efficiency.

HD wide-angle lens presents a wider and clearer world

Tenveo Vloop 12U is equipped with lens of wide angle up to 70 degrees, which means the camera could cover a wide range and provides a spectacular view. It will surprise you with its quiet and smooth rotation (tilt rotation: ±90°, pan rotation: ±175°).

Technical Specifications

• Model No.: VL12U
• Item Name: USB3.0 / HDMI PTZ Camera with 12x zoom
• Image Sensor: Sony IMX415 1/2.8″ CMOS
• Effective Pixels: 8.29MP, 16:9
• Lens: f=3.9–46.8mm
• Aperture: F1.6～F9.6
• Video Format:
  • HDMI (4KP@30/25fps, 1080P@60/50/30/25fps, 720P@60/50/30/25fps);
  • USB3.0 (3840×2160P@30fps, 2560×1440P@30fps, 1920×1080P@30fps, 1280×720P@30fps, 640×480P@30fps, 320×240P@30fps;
  • YUY2/NV12/H.264/H.265/MJPG)
• Optical Zoom: 12x zoom
• Horizontal Angle: 70.82°(W)–6.48°(T)
• Vertical Angle: 47.72°(W)–73.66°(T)
• Diagonal Angle: 78.58°(W)–7.42°(T)
• Backlight Compensation: Support
• SNR: >50dB
• Focus: Auto / Manual
• Digital Noise Reduction: 2D & 3D Noise Reduction
• Exposure: Auto / Manual
• Video Interfaces: HDMI, TYPE-C, RJ45
• Video Compression Format: H.264, H.265, MJPG, YUY2
• LAN: 10M/100M adaptive Ethernet port; Support POE IEEE802.3af
• Network Protocol: NDI|HX2, RTSP, RTMP, ONVIF, GB28181; Support VISCA Over IP
• Control Protocol: VISCA/Pelco-D/Pelco-P; Baud Rate: 9600/4800/38400/2400
• Control Interface: RS232 (input & output), RS485, TYPE-C(UVC1.1)
• Pan/Tilt Rotation: ±175°, -90°～+90°
• Pan Control Speed: 0.1–80°/sec
• Tilt Control Speed: 0.1–60°/sec
• Preset Number: 255 presets by Pelco-D, 32 presets by Pelco-P, 7 presets by Visca (10 presets by remote controller)
• Operation Systems: Windows 7, Windows 8.1, Windows 10, Windows 11; Android, Mac OS™ 10.10 or higher, Linux (Require to support UVC.)
• Input Voltage: DC 12V
• Input Current: 2.0A (Max.)
• Power Consumption: 13W (Max.)
• Store Temperature: -10℃～+60℃
• Store Humidity: 20%～90%
• Working Temperature: -10℃～+50℃
• Working Humidity: 20%～80%
• Dimension (W*H*D): 171.6*192.6*171.6mm / 260*217*197mm (before/after packing)
• Weight: 1.35kg / 2.05kg (Net / Gross weight)
• Accessory: 1 x Camera; 1 x USB Cable; 1 x Power Adapter; 1 x Wall Mount; 1 x Manual
• Mfg. Warranty: 3 Years Parts & Labor
