Description
| HARDWARE FEATURES | |
|---|---|
| Standards and Protocols |
IEEE 802.3, IEEE802.3u, IEEE802.3ab TCP/IP, DHCP, ICMP, NAT, PPPoE, SNTP, HTTP, DNS, IPsec, PPTP, L2TP |
| Interface |
2 Gigabit WAN ports 2 Gigabit LAN ports 1 Gigabit LAN/DMZ port 1 Console Port (RJ-45 On RS232) |
| Network Media |
10BASE-T: UTP category 3, 4, 5 cable (Max 100m) EIA/TIA-568 100Ω STP (Max 100m) 100BASE-TX: UTP category 5, 5e cable (Max 100m) EIA/TIA-568 100Ω STP (Max 100m) 1000BASE-T: UTP category 5, 5e, 6 cable (Max 100m) |
| Fan Quantity | Fanless |
| Button | Reset Button |
| Power Supply |
Internal Universal Power Supply AC100-240V~ 50/60Hz Input |
| Flash | 16MB |
| DRAM | DDRII 128MB |
| LED | PWR, SYS, Link/Act, Speed, DMZ |
| Dimensions ( W x D x H ) |
11.6*7.1*1.7in. (294*180*44mm) 13-inch Standard Rack-Mount Width, 1U Height |
| PERFORMANCE | |
|---|---|
| Concurrent Session | 30000 |
| NAT Throughput | 180Mbps |
| IPsec VPN Throughput (3DES) | 80Mbps |
| BASIC FUNCTIONS | |
|---|---|
| WAN Connection Type | Dynamic IP, Static IP, PPPoE, PPTP, L2TP, Dual Access, BigPond |
| MAC Clone | Modify WAN/LAN/DMZ MAC Address |
| DHCP |
DHCP Server/Client DHCP Reservation |
| Switch Setting |
Port Mirror Rate Control Port Config Port VLAN |
| IPv6 | IPv6 Support |
| VLAN | 802.1Q VLAN, Port VLAN |
| IPTV | Bridge, Custom |
| ADVANCED FUNCTIONS | |
|---|---|
| Load Balance |
Intelligent Load Balance Policy Routing Protocol Binding Link Backup (Timing, Failover) Online Detection |
| NAT |
One-to-One NAT Multi-nets NAT Virtual Server, DMZ Host, Port Triggering, UPnP FTP/H.323/SIP/IPsec/PPTP ALG |
| Routing |
Static Routing Dynamic Routing (RIP v1/v2) |
| System Mode | NAT, Non-NAT, Classical Routing |
| Traffic Control |
IP-based Bandwidth Control Guarantee & Limited Bandwidth Time-scheduled Policy IP-based Session Limit |
| TRANSMISSION | |
|---|---|
| Load Balance |
Intelligent Load Balance Link Backup (Timing, Failover) Online Detection |
| NAT |
One-to-One NAT Multi-nets NAT Virtual Server Port Triggering FTP/H.323/SIP/IPsec/PPTP ALG UPnP |
| Routing |
Static Routing Policy Routing |
| Session Limit | IP-based Session Limit |
| Bandwidth Control | IP-based Bandwidth Control |
| VPN | |
|---|---|
| IPsec VPN |
50 IPsec VPN Tunnels LAN-to-LAN, Client-to-LAN Main, Aggressive Negotiation Mode DES, 3DES, AES128, AES192, AES256 Encryption Algorithm MD5, SHA1 Authentication Algorithm Manual, IKE Key Management Mode IPsec NAT Traversal (NAT-T) Dead Peer Detection (DPD) Perfect Forward Secrecy (PFS) |
| PPTP VPN |
16 PPTP VPN Tunnels PPTP VPN Server/Client PPTP with MPPE Encryption |
| L2TP VPN |
16 L2TP VPN Tunnels L2TP VPN Server/Client L2TP over IPsec |
| VPN Pass-through | IPsec (ESP), PPTP, L2TP |
| SECURITY | |
|---|---|
| DMZ Port | 1 Hardware DMZ Port |
| Application Control | IM, P2P, Web IM, Web SNS, Web Media, Protocol, Proxy Blocking |
| Filtering |
MAC Filtering URL/Keywords Filtering Web Content Filtering (Java, ActiveX, Cookies) |
| ARP Inspection |
Sending GARP Packets ARP Scanning by WAN/LAN IP-MAC Binding |
| Attack Defense |
TCP/UDP/ICMP Flood Defense Block TCP Scan (Stealth FIN/Xmas/Null) Block Ping from WAN |
| Access Control | Source/Destination IP Based Access Control |
| AUTHENTICATION | |
|---|---|
| Web Authentication |
Local User Authentication, Radius Sever Authentication, Onekey Online |
| MANAGEMENT | |
|---|---|
| Service |
PPPoE Server E-Bulletin Dynamic DNS (Dyndns, No-IP, Peanuthull, Comexe) |
| Maintenance |
Web/CLI/Telnet Management Interface Remote Management Export & Import Configuration NTP Synchronize Syslog Support |
| OTHERS | |
|---|---|
| Certification | CE, FCC, RoHS |
| Package Contents |
TL-ER6020 Resource CD Power Cord Ground Cable Rack-mount Kit Installation Guide |
| System Requirements | Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7, MAC® OS, NetWare®, UNIX® or Linux |
| Environment |
Operating Temperature: 0℃~40℃ (32℉~104℉) Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
