Description
The Yealink MeetingBar A50 is an all-in-one video collaboration bar for premium medium-to-large rooms. This product delivers cutting-edge audio and video communication capabilities, powered by advanced AI technology, ensuring crystal-clear sound and ultra-HD visuals. With intelligent full-duplex, IntelliFocus, and video fence, it redefines the video conferencing experience, bringing unparalleled clarity and efficiency to every meeting.
Yealink MeetingBar A50 is compatible with Microsoft’s MDEP*, which enhances security and deployment experiences. This integration provides users with a more secure environment and streamlined deployment processes, contributing to a smoother and safer user experience.
Moreover, Yealink MeetingBar A50 features a direct connection to CTP25, enabling a simplified login process. This streamlined login experience saves users time and enhances convenience.
In addition, MeetingBar A50 seamlessly supports Microsoft Teams Rooms (MTR), delivering a consistent and efficient experience whether you’re using the Android or Windows version. In MTR-W, it is namely MVC S50.
*Support 3x expansion microphones: Optional
Key Features And Benefits
Ultra HD picture quality and artificial AI features
The MeetingBar A50 has a built-in triple-camera system, each with 50MP resolution—one for wide-angle and two for telephoto, ensuring high-resolution imaging across different focal lengths. The professional-grade lens delivers low grain, natural colors, and HD image quality. It also features a built-in automatic physical privacy shutter that blocks the camera when not in use, ensuring user privacy. Intelligent AI features include IntelliFocus, Multi-stream IntelliFrame with Copilot (only for MTR-W), Video Fence, and more. It can automatically detect speakers in the meeting room, frame them, and display them on the screen through multi-stream output, providing a more intuitive and interactive remote meeting experience.
High-quality audio pickup experience
Yealink MeetingBar A50 has a 10-meter voice pickup range, built-in stereo speakers, and a 16x MEMS microphone array. Intelligent noise reduction technology provides a good audio experience. In addition, it supports up to 3 additional expansion microphones, covering large conference rooms.
Compatible with Microsoft’s MDEP
Yealink MeetingBar A50 is compatible with Microsoft’s MDEP, which enhances security and deployment experiences. This integration provides users with a more secure environment and streamlined deployment processes, contributing to a smoother and safer user experience.
Multi-platform flexibility
Yealink MeetingBar A50 supports native Teams, Zoom, and other platforms. Additionally, it supports wired General Mode. In BYOD mode, MeetingBar A50 serves as a peripheral for meetings held through third-party applications.
Simple deployment
Yealink MeetingBar A50 features a direct connection to CTP25, enabling a simplified login process with only one login required. This streamlined experience saves users time and enhances convenience.
Remote device management
The Yealink MeetingBar A50 connects to the network and reports to the device management platform, enabling remote management, configuration, and upgrades.
Specifications
|
Parameter
|
Description
|
|
Operating System
|
• Android 13 • Based on the Microsoft Device Ecosystem Platform (MDEP) |
|
Camera
|
• Number of Cameras: 3 • Lens FOV: • 1x Wide Camera: DFOV 110°, HFOV 98°, VFOV 81° • 2x Tele Cameras: DFOV 51°, HFOV 41.6°, VFOV 31.8° • Maximum Pixels: 3x 50MP • Number of Preset Positions: 9 • Electronic Gimbal • Depth of Field: 0.7–8 Meters • Digital Zoom: 8x • Maximum Resolution: 3840 × 2160 • Video Output Resolution: 4K (2160p) 30fps, 1080p 60fps • Effective Focal Length: 8.29 mm (Tele Camera), 3.5 mm (Wide Camera) • Aperture: F/2.0–F/2.4 • Supports Wide Dynamic Range • Supports Auto Exposure • White Balance: ATW/Auto/Manual • Shutter Speed: 10–33 ms • Minimum Illumination: 0.5 lux (Daytime), 0.1 lux (Nighttime) • Privacy Cover: Electric Lens Cap • Lens Calibration • Intelligence Features: • IntelliFocus (4 Portraits) • Auto Framing • Speaker Tracking • People Counting • Picture-in-Picture • Smart Gallery (Zoom Only) |
|
Speaker
|
• Built-in 4 × 5W Speakers: • Rated Power: 4 × 5W • Maximum Power: 4 × 10W • Maximum Sound Pressure Level: 97 dBSPL @ 10W @ 1m • Frequency Response: 80–20kHz • Sensitivity: 104 ± 3dB, 1W/0.1m • Sampling Rate: 48kHz • Sound Emission Angle: 0–180° • Total Harmonic Distortion (THD): <3% @ 1kHz (Rated) • Rated Impedance: 4 ohms |
|
Microphone
|
• Built-in 16 MEMS Microphone Array, 10 Meters Pickup Distance • Signal-to-Noise Ratio: 72dB @ 1kHz • Maximum Sound Pressure Level: 130dBSPL (Whole Device), 100dBSPL (Individual Microphone) • Dynamic Range: 22–108dBSPL • Sensitivity: -38dBV/Pa • Frequency Response: 100–20kHz • Sampling Rate: 48kHz • Bit Depth: 32-bit • Audio Processing: Full Duplex, AEC (Acoustic Echo Cancellation), AGC (Automatic Gain Control) • Noise Suppression: AI-Enhanced Noise Suppression • Expansion Mics: Supports 3 Expansion Microphones |
|
Resolution
|
• Lens Resolution: Up to 4K 30fps • Bandwidth Requirement: 10Mbps or More |
|
Content Sharing
|
• Teams: 1080p 30fps In Meetings, 4K 30fps In Local Sharing • Zoom: Up to 1080p 30fps • General Mode (BYOM): Up to 4K 30fps • RingCentral: 1080p 30fps • H.323/SIP: 1080p 30fps |
|
Video Codec
|
• H.264 High Profile • H.264 SVC • H.264 |
|
Audio Codec
|
• ARES: 24kHz Bandwidth • G.722.1C: 16kHz Bandwidth • G.722.1: 8kHz Bandwidth • G.722: 8kHz Bandwidth • G.711 (PCMA/PCMU): 4kHz Bandwidth • G.729: 8kHz Bandwidth |
|
Security
|
• Full Disk Encryption: AES-128, AES-256 • Data Encryption: Symmetric Keys, PKI • Device Identity: Protected by Device Attestation • Device Access: Authenticated Using API • Key Protection: Arm TrustZone, RPMP |
|
Communication Standard Protocol
|
• H.323/SIP In General Mode (BYOM) • Dual Stream Protocol: H.239 (H.323) / BFCP (SIP) • FECC: H.224/H.281 • H.323 Protocol Suite: H.245, H.225, H.235, H.241 • Gatekeeper Account And SIP Account |
|
Network Protocol
|
• Wi-Fi 6: • 2.4G And 5G Dual-Band: 802.11a/b/g/n/ac/ax • 2×2 MIMO • Bluetooth 5.0 • TCP/IP (IPv4/IPv6), DHCP/Static IP • HTTPS Secure Web Access |
|
Configuration Management
|
• Automatic Configuration Via Web Page/Display/AutoP • Firmware Upgrade And Factory Reset • Configuration Import And Export • System Log Export |
|
Device Management
|
• Yealink HTTPS Web Portal • Yealink Device Management Platform • Yealink Management Cloud Service • Microsoft Device Management Platform (Microsoft Teams Admin Center/Intune) • Zoom Device Management • RingCentral Admin Center |
|
Installation
|
• Wall Mount (Included: VB-WallMount-02) • TV Mount (Optional: VB-TVMount-01, In Roadmap) • Table Mount (Optional: VB-TabletopMount-02) |
|
Ports
|
• 1x USB 3.0 Type-A Port • 1x USB 3.0 Type-B Port: • Video Output: Up To 4K 30fps, Including 1080p 60fps • 1x USB 2.0 Type-C Port (For Dongle Pairing) • 1x Ethernet Port: 10/100/1000Mbps • 2x Yealink VCH Ports (RJ-45) • 1x 3.5mm Line-In And Line-Out Port • 1x Power Port • 1x Security Lock Slot • 1x Reset Slot • 2x HDMI-Out: • Video Output: Up To 4K 30fps, Including 1080p 60fps • Supports HDMI CEC |
|
Package
|
• MeetingBar A50 • Power Adapter: 3.5m/11.48ft • HDMI 2.0 Cables: 2x, 1.8m/5.91ft • Network Cable: 1x, 3m/9.84ft • USB 3.0 A-B Cable: 1x, 2.5m/8.20ft • Wall Mount (VB-WallMount-02) • Table Mount (VB-TabletopMount-02) • Cable Cover • MeetingBar A50 Quick Start Guide • Optional Package: • A50-010: A50 + VCR11 • A50-031: A50 + CTP25 Package (CTP25, 2m/6.56ft 65W PD Power Adapter, 7.5m/24.6ft Network Cable, 1.2m/3.94ft USB C-to-C Cable, High Stand, Cable Management Cover) |
|
Environmental Factor
|
• Operating Humidity: 10–95% • Operating Temperature: 0–40℃ • Storage Temperature: -30℃ to 70℃ • BTU/hr: 38 (Idle), 58 (Meeting) |
|
Dimensions And Weight (W × D × H)
|
• MeetingBar A50: 910 × 102 × 88mm • N.W/CTN: 8.5kg • G.W/CTN: 9.5kg |
|
Warranty
|
• Standard: 2-Year Limited Hardware Warranty Included • Extended: Additional Extended Warranties Are Available At The Time Of Hardware Purchase. Contact Your Reseller. |
