Description
Product Features
»Room Booking & Real-Time Status Updates
Dual-sided tricolor LED strips display meeting room status—available, reserved, or occupied—making it simple to book and track room availability.
»One-Touch Meeting Control
Pre-installed with popular meeting apps like Zoom, this feature allows you to start, join, manage, and end meetings, as well as share your screen, all with a single touch. Simplifying your video conferencing experience.
»Full HD Touchscreen
Experience a crystal-clear display and smooth operation with the 10.1-inch IPS Full HD touchscreen powered by a hexa-core processor.
»Remote Power Supply and Management
The device supports PoE and network connectivity, simplifying the wiring.
»Diverse Installation Options
This control panel features standard VESA positions for walls, glass, doors, window frames, with a back panel for cable management, supporting horizontal, vertical, and desktop mounting.
Specifications
»DISPLAY
- Screen: 10.1-inch, IPS
- Screen Type: IPS Multi-touch Display
- Resolution: 1920 x 1200
- Display Luminance: 300 cd/m2 (typ)
- Display Ratio: 16:10
- Viewing Angle: 170°
»HARDWARE
- CPU: hexa-core, 4 x Cortex A73 + 2 x Coretex A53
- Memory: 4GB
- Storage: 16GB
- Image Processor: ARM G52 MP4
- OS: Android 9.0
- Speaker: 1 × 1.2W
- Microphone: Built-in
- Status Light Strip: Built-in Dual-Side Indicator Light Strip
»I/O
- USB: 1 x USB2.0 Type-C (Supports power supply and data transmission)
- RJ45: 1 x RJ45 (PoE): 10/100 Base-T
»SOFTWARE
- Pre-installed Software (choose one):
- Zoom Rooms Controller APK
- Zoom Rooms Check-in Board APK
»NETWORK
- WIFI: IEEE802.11a/b/g/n/ac, WPA，WPA2
- Ethernet: 10/100 MBaseT
- Bluetooth: BT5.0
- PoE: Support
»MULTIMEDIA
- Video Coding Format: H.264/H.265，Supports up to 1080P60
- Picture Format: JPEG, JPG, PNG, BMP and other common formats
- Video Decoding Format: VP9 / H.265 /H.264 /AVS2-P2, Supports up to 4Kx2K@60fps
»GENERAL
- Input Voltage: DC 5V / PoE (802.3af)
- Input Current: 3.0A
- Operating Temperature: 0°C ~ 40°C
- Storage Temperature: -40°C ~ 60°C
- Working Humidity: 10% ~ 80%
- Storage Humidity: 0% ~ 95%
- Power Consumption: 12W
- MTBF: >30000 Hours
- Dimension: 242mm (W) × 162mm (D) × 29mm (H)
- Net Weight: 800g
WHAT’S IN THE BOX
- ›1 x RT13
- ›1 x USB Cable
- ›1 x Network Cable
- ›1 x Quick Start Guide
